In  good condition both technically and cosmetically. minor scuff and scratch marks that in no way affect its operation.
Presently loaded with Windows XP plus Koltz software for control of Koltz radio broadcast systems.

30 day guarantee that is will work to your satisfaction upon arrival.

Delivery options available to anywhere in the World.

Please Note; The photographs show the unit with the optional stand/bracket attached. Although we hold about 10 of these monitors in stock, there are only 5 with the stands. The stands are provided free for the first five purchases only.

AFL-08AH-N270/WT-R/1GB-R10 TFT LCD Fanless Touch Panel PC
Intel® Atom™ N270 1.6GHz Processor

Windows XP

7

● 8.4” TFT LCD with resistive touch screen

● 12V DC power input

● Fanless cooling system

● Selectable AT/ATX power mode

● System memory up to 2GB SDRAM

● Built-in 802.11b/g Wireless LAN

● Built-in Bluetooth module

● Built-in two 1.5 W speakers

● One compact flash slot

● IP 64 compliant front panel

Max Resolution: 800 x 600

Brightness (cd/m²): 450

Contrast Ratio: 600:1

LCD Color: 262K

Pixel Pitch (mm): 0.213(H) x 0.213(V)

Viewing Angle (H-V): 140º/120º

Backlight MTBF: 50000 hrs

SBC : Model: AFLMB-945GSE-N270-R10

CPU: AMD LX 800 (500MHz)

Intel® Atom™ process N270 1.6GHz CPU

Chips: set: Intel® 945GSE + ICH7M

RAM: Supports one 400MHz or 533MHz DDRII SO-DIMM (2GB Max.)

1 x RS232 COM Port

1 x RS-232/422/485 COM port

2 x RJ-45 for Giga LAN

2 x USB 2.0

1 x Power Switch

1 x Reset Button

1 x External SATA

1 x Audio Port

1 x Power Jack

SSD

CF TypeII

Watchdog Timer

Software programmable supports 1~255 sec. System reset

Audio

AMP 1.5W + 1.5W (internal speaker)

Expansion: 1 x Wireless Lan 802.11 b/g Module (internal PCIe mini card interface) , 1 x Bluetooth Function (internal USB interface, Bluetooth V2.0)

 (WxHxD) (mm): 234 x 184 x 42

-
